TechnipFMC Smith Meter AccuLoad III User Manual

Section IV – Diagrams
MN06135 Issue/Rev. 1.3 (6/17) 18
Dual Pulse Inputs for Rev. 10.07 and Above Firmware (With Flow Controlled Additive)
5 Product Meters with 1 Flow Controlled Additive (AccuLoad III – Q Hardware)
Input #1 Input #2 Input #3 Input #4 Input #5 Input #6
Dual Pulse
Meter #1A Meter #1B Meter #3A Meter #2A Meter #2B Meter #3B
Dual/Integrity
NA NA NA NA NA NA
Input #7 Input #8 Input #9 Input #10 Input #11 Input #12
Dual Pulse
Meter #4A Meter #4B FC Inj #1A Meter #5A Meter #5B FC Inj #1B
Dual/Integrity
NA NA NA NA NA NA
4 Product Meters with 2 Flow Controlled Additive (AccuLoad III – Q Hardware)
Input #1 Input #2 Input #3 Input #4 Input #5 Input #6
Dual Pulse Meter #1A Meter #1B Meter #3A Meter #2A Meter #2B Meter #3B
Dual/Integrity NA NA NA NA NA NA
Input #7 Input #8 Input #9 Input #10 Input #11 Input #12
Dual Pulse
Meter #4A Meter #4B FC Inj #2A FC Inj #1A FC Inj #1B FC Inj #2B
Dual/Integrity
NA NA NA NA NA NA
4 Product Meters with 1 Flow Controlled Additive (AccuLoad III – Q Hardware)
Input #1 Input #2 Input #3 Input #4 Input #5 Input #6
Dual Pulse
Meter #1A Meter #1B Meter #3A Meter #2A Meter #2B Meter #3B
Dual/Integrity NA NA NA NA NA NA
Input #7 Input #8 Input #9 Input #10 Input #11 Input #12
Dual Pulse
Meter #4A Meter #4B Injector/Dens FC Inj #1A FC Inj #1B Injector/Dens
Dual/Integrity NA NA NA NA NA NA
3 Product Meters with 3 Flow Controlled Additive (AccuLoad III – Q Hardware)
Input #1 Input #2 Input #3 Input #4 Input #5 Input #6
Dual Pulse Meter #1A Meter #1B Meter #3A Meter #2A Meter #2B Meter #3B
Dual/Integrity
NA NA NA NA NA NA
Input #7 Input #8 Input #9 Input #10 Input #11 Input #12
Dual Pulse FC Inj #1A FC Inj #1B FC Inj #3A FC Inj #2A FC Inj #2B FC Inj #3B
Dual/Integrity
NA NA NA NA NA NA
3 Product Meters with 2 Flow Controlled Additive (AccuLoad III – Q Hardware)
Input #1 Input #2 Input #3 Input #4 Input #5 Input #6
Dual Pulse
Meter #1A Meter #1B Meter #3A Meter #2A Meter #2B Meter #3B
Dual/Integrity
NA NA NA NA NA NA
Input #7 Input #8 Input #9 Input #10 Input #11 Input #12
Dual Pulse FC Inj #1A FC Inj #1B Injector/Dens FC Inj #2A FC Inj #2B Injector/Dens
Dual/Integrity NA NA NA NA NA NA
