TechnipFMC Smith Meter AccuLoad III User Manual

Section IV – Diagrams
MN06135 Issue/Rev. 1.3 (6/17) 71
Additive Solenoids 1 through 4 are wired to the programmed terminals on the EAAI board. Additive Solenoids 3
through 12 (AccuLoad III-S hardware) or Additive Solenoids 5 through 24 (AccuLoad III-Q hardware) are wired
per the following table. Terminals are automatically assigned as additive solenoids if metered injectors are pro-
grammed in the AccuLoad.
Table 17. Additive Solenoids (Optional AICB #1 and #2)
Additive Solenoids (Optional AICB #1)
Additive Solenoid #
ALIII-S Hardware ALIII-Q Hardware Terminal +V Terminal Block
5 5 9 TB8
6 6 7 TB8
7 7 5 TB8
8 8 3 TB8
9 9 1 TB8
10 10 9 TB7
11 11 7 TB7
12 12 5 TB7
13 13 3 TB7
14 14 1 TB7
Additive Solenoids (Optional AICB #2)
N/A 15 9 TB8
N/A 16 7 TB8
N/A 17 5 TB8
N/A 18 3 TB8
N/A 19 1 TB8
N/A 20 9 TB7
N/A 21 7 TB7
N/A 22 5 TB7
N/A 23 3 TB7
N/A 24 1 TB7
