TechnipFMC Smith Meter AccuLoad III User Manual

Section IV – Diagrams
MN06135 Issue/Rev. 1.3 (6/17) 73
Optional AICB Board(s) (General Purpose Inputs/Outputs)
DC Inputs (Optional AICB #1)
Input # Terminal Block Signal Common
24 TB5 2 3
25 TB5 5 6
26 TB5/TB4 8 (TB5) 1 (TB4)
27 TB4 3 4
28 TB4 6 7
29 TB4 9 10
30 TB3 2 3
31 TB3 5 6
32 TB3 8 9
33 TB3 11 12
DC Inputs (Optional AICB #2) (Not Applicable to ALIII-S Hardware)
34 TB5 2 3
35 TB5 5 6
36 TB5/TB4 8 (TB5) 1 (TB4)
37 TB4 3 4
38 TB4 6 7
39 TB4 9 10
40 TB3 2 3
41 TB3 5 6
42 TB3 8 9
43 TB3 11 12
Table 20. Optional AICB DC Inputs
