Section IV – Diagrams
MN06135 Issue/Rev. 1.3 (6/17) 69
Optional AICB Board(s) (Additive Inputs/Outputs)
Terminal connections for the optional AICB board are shown in
Figure 6. Metered Additive Pulses 1 and 2 (AccuLoad III-S) or Metered Additive Pulses 1 through 4 (AccuLoad III-Q)
are wired into the PIB board on the EAAI board. Metered Additives 5 through 24 are wired to the AICB board(s).
Connections are shown in the table below.
Meter Pulses (Optional AICB #1)
Injector # Metered Additive Pulses
ALIII-S
Hardware
ALIII-Q
Hardware
Terminal Block + Voltage Signal Common
5 5 TB5 1 2 3
6 6 TB5 4 5 6
7 7 TB5, TB4 7 (TB5) 8 (TB5) 1 (TB4)
8 8 TB4 2 3 4
9 9 TB4 5 6 7
10 10 TB4 8 9 10
11 11 TB3 1 2 3
12 12 TB3 4 5 6
13 13 TB3 7 8 9
14 14 TB3 10 11 12
Meter Pulses (Optional AICB #2)
N/A 15 TB5 1 2 3
N/A 16 TB5 4 5 6
N/A 17 TB5, TB4 7 (TB5) 8 (TB5) 1 (TB4)
N/A 18 TB4 2 3 4
N/A 19 TB4 5 6 7
N/A 20 TB4 8 9 10
N/A 21 TB3 1 2 3
N/A 22 TB3 4 5 6
N/A 23 TB3 7 8 9
N/A 24 TB3 10 11 12
Table 15. Meter Pulses (Optional AICB #1 and #2)
