TechnipFMC Smith Meter AccuLoad III User Manual

Section IV – Diagrams
MN06135 Issue/Rev. 1.3 (6/17) 19
3 Product Meters with 1 Flow Controlled Additive (AccuLoad III – Q Hardware)
Input #1 Input #2 Input #3 Input #4 Input #5 Input #6
Dual Pulse
Meter #1A Meter #1B Injector/Dens Meter #2A Meter #2B Injector/Dens
Dual/Integrity
Meter #1A Meter #1B Meter #1 Bar Meter #2A Meter #2B Meter #2 Bar
Input #7 Input #8 Input #9 Input #10 Input #11 Input #12
Dual Pulse
Meter #3A Meter #3B Injector/Dens FC Inj #1A FC Inj #1B Injector/Dens
Dual/Integrity
Meter #3A Meter #3B Meter #3 Bar FC Inj #1A FC Inj #1B FC Inj #1 Bar
2 Product Meters with 4 Flow Controlled Additive (AccuLoad III – Q Hardware)
Input #1 Input #2 Input #3 Input #4 Input #5 Input #6
Dual Pulse
Meter #1A Meter #1B FC Inj #1A Meter #2A Meter #2B FC Inj #1B
Dual/Integrity
NA NA NA NA NA NA
Input #7 Input #8 Input #9 Input #10 Input #11 Input #12
Dual Pulse
FC Inj #2A FC Inj #2B FC Inj #4A FC Inj #3A FC Inj #3B FC Inj #4B
Dual/Integrity
NA NA NA NA NA NA
2 Product Meters with 3 Flow Controlled Additive (AccuLoad III – Q Hardware)
Input #1 Input #2 Input #3 Input #4 Input #5 Input #6
Dual Pulse
Meter #1A Meter #1B FC Inj #1A Meter #2A Meter #2B FC Inj #1B
Dual/Integrity
NA NA NA NA NA NA
Input #7 Input #8 Input #9 Input #10 Input #11 Input #12
Dual Pulse
FC Inj #2A FC Inj #2B Injector/Dens FC Inj #3A FC Inj #3B Injector/Dens
Dual/Integrity
NA NA NA NA NA NA
2 Product Meters with 2 Flow Controlled Additive (AccuLoad III – Q Hardware)
Input #1 Input #2 Input #3 Input #4 Input #5 Input #6
Dual Pulse
Meter #1A Meter #1B Injector/Dens Meter #2A Meter #2B Injector/Dens
Dual/Integrity
Meter #1A Meter #1B Meter #1 Bar Meter #2A Meter #2B Meter #2 Bar
Input #7 Input #8 Input #9 Input #10 Input #11 Input #12
Dual Pulse
FC Inj #1A FC Inj #1B Injector/Dens FC Inj #2A FC Inj #2B Injector/Dens
Dual/Integrity
FC Inj #1A FC Inj #1B FC Inj #1 Bar FC Inj #2A FC Inj #2B FC Inj #2 Bar
2 Product Meters with 1 Flow Controlled Additive (AccuLoad III – Q Hardware)
Input #1 Input #2 Input #3 Input #4 Input #5 Input #6
Dual Pulse
Meter #1A Meter #1B Injector/Dens Meter #2A Meter #2B Injector/Dens
Dual/Integrity
Meter #1A Meter #1B Meter #1 Bar Meter #2A Meter #2B Meter #2 Bar
Input #7 Input #8 Input #9 Input #10 Input #11 Input #12
Dual Pulse
FC Inj #1A FC Inj #1B Injector/Dens Reserved Reserved Injector/Dens
Dual/Integrity
FC Inj #1A FC Inj #1B FC Inj #1 Bar Injector/Dens Injector/Dens Injector/Dens
