Section IV – Diagrams
MN06135 Issue/Rev. 1.3 (6/17) 20
1 Product Meters with 4 Flow Controlled Additive (AccuLoad III – Q Hardware)
Input #1 Input #2 Input #3 Input #4 Input #5 Input #6
Dual Pulse
Meter #1A Meter #1B FC Inj #2A FC Inj #1A FC Inj 1 B PC Inj #2B
Dual/Integrity
NA NA NA NA NA NA
Input #7 Input #8 Input #9 Input #10 Input #11 Input #12
Dual Pulse
FC Inj #3A PC Inj #3B Injector/Dens FC Inj #4A FC Inj #4B Injector/Dens
Dual/Integrity
NA NA NA NA NA NA
1 Product Meters with 3 Flow Controlled Additive (AccuLoad III – Q Hardware)
Input #1 Input #2 Input #3 Input #4 Input #5 Input #6
Dual Pulse
Meter #1A Meter #1B Injector/Dens FC Inj #1A FC Inj 1 B Injector/Dens
Dual/Integrity
Meter #1A Meter #1B Meter #1 Bar FC Inj #1A FC Inj 1 B FC Inj #1 Bar
Input #7 Input #8 Input #9 Input #10 Input #11 Input #12
Dual Pulse
FC Inj #2A PC Inj #2B Injector/Dens FC Inj #3A FC Inj #3B Injector/Dens
Dual/Integrity
FC Inj #2A PC Inj #2B PC Inj #2 Bar FC Inj #3A FC Inj #3B FC Inj #3 Bar
1 Product Meters with 2 Flow Controlled Additive (AccuLoad III – Q Hardware)
Input #1 Input #2 Input #3 Input #4 Input #5 Input #6
Dual Pulse
Meter #1A Meter #1B Injector/Dens FC Inj #1A FC Inj 1 B Injector/Dens
Dual/Integrity
Meter #1A Meter #1B Meter #1 Bar FC Inj #1A FC Inj 1 B FC Inj#1 Bar
Input #7 Input #8 Input #9 Input #10 Input #11 Input #12
Dual Pulse
FC Inj #2A PC Inj #2B Injector/Dens Reserved Reserved Injector/Dens
Dual/Integrity
FC Inj #2A PC Inj #2B PC Inj #2 Bar Injector/Dens Injector/Dens Injector/Dens
