Quick Start User Manual Information
Environmental
Requirements
Characteristic Description
Humidity, ope
rating
20% to 80% relative humidity with a maximum
wet bulb temperature of +29 °C (+84.2 °F) at
or below +45 °
C(+113°F)noncondensing.
Upper limit derated to 30% relative humidity
at +45 °C (+113 °F)
Altitude, operating
9,842 ft. (3,000 m)
Temperature, ambient operating
+5 °C to + 45 °C (+41 °F to +113 °F)
Maximum voltage
1MΩ input impedance 150 VRMS CAT I, and ≤400 peak
For steady-state sinusoidal waveforms,
derate at 2
0dB/decadeabove200kHzto
9VRMSat≥3MHz
50 Ω input impedance <1 Vrms for settings below 100 mV/div
<5 Vrms for 100 mV/div settings and above
TDS5000B Read This First 9
