Tektronix TDS5000B Series Read This First

Service Manual Information
Replaceable Parts
Use the following information to replace or clarify parts list information in the
service manual.
External parts
Fig. &
index
number
Tektronix
part
number
Serial no.
effective
Serial no.
discont’d Qty Name&description
10-1-(not
shown)
101-0158-xx B030000 1
TRIM RING; FR110,PC/ABS
Inner Pane
ls
Fig. &
index
number
Tektronix
part
number
Serial no.
effective
Serial no.
discont’d Qty Name&description
10-2-10
441-2226-xx B010100 B019999 1
CHASSIS ASSY;FOR ASHLAND MOTHER BOARD,0.050 AL
W/BRACKETS & HARDWARE
441-2376-xx B020000 B029999 1
CHASSIS ASSY;FOR LACROSSE MOTHER BOARD,0.050 AL
W/BRACKETS & HARDWARE
441-2491-xx B030000 B039999 1
CHASSIS ASSY;FOR TAPPEN MOTHER BOARD,0.050 AL
W/BRACKETS & HARDWARE
441-2557-xx B040000 1
CHASSIS ASSY;FOR ADVANTECH MOTHER BOARD,0.050 AL
W/BRACKETS & HARDWARE
Modul
es
Fig. &
index
number
Tektronix
part
number
Seria
lno.
effective
Seria
lno.
discont’d Qty Name&description
10-3-5
039-0154-xx B010100 B019999 1
MOTHER BOARD ASSY;PENTIUM 4/CELERON BD, UATX,ASHLAND
2.1,W/O PROCESSOR,D845GVAD2L
039-0159-xx B020000 B029999 1
MOTHER BOARD ASSY;PENTIUM 4/CELERON BD, UATX,LA
CROSSE,W/O PROCESSOR,BLKD865GLCLK INTEL P/N,SAFETY
CONTROLLED
039-0173-xx B030000 B039999 1
MOTHER BOARD ASSY;PENTIUM 4, UATX,TAPPEN
BD,GIG E, PROCESSOR LGA775,DDR2 667MHZ,TOTAL 4
GIG,BLKD945GTPLKR,SAFETY CONTROLLED
039-0185-xx B040000 1
MOTHER BOARD ASSY;ADVANTECH MICROATX, LGA 775
CORE 2 DUO, DDR2, PCI-E X1, SINGLE GBE LAN; ADVANTECH
AIMB-562VG-00A1E WITH ADD2 DISABLE AND BIOS 562X126N.BIN
SAFETY CONTROLLED
28 TDS5000B Read This First
