Tektronix TDS5000B Series

Removal and Inst a l l a t i on Procedures
6-- 16
TDS5000B Series Se r vi c e Manual
T-15 TORX drive
screws (15)
Right side cover
Tab
Figure 6--4: Right-side cover removal (SN B030000 and above)
T-15 TORXdrive
screws (15)
Right side cover
Tab
Note: Be sure to reinstall the
shorter screw here--do not
use another (longer) screw.
Figure 6--5: Right-side cover removal (SN B029999 and below)
