Tektronix TDS5000B Series

Removal and Inst a l l a t i on Procedures
6-- 18
TDS5000B Series Se r vi c e Manual
Printer
frame
Right side
cover
T-15 TORX
drive screw (2)
Cable
restraint
T-15
TORX
drive
screw (4)
Printer
cable
Figure 6--6: Printer frame removal
4. Reverse the pr oc e dur e to reinstal l .
