TDS5000B Series Service Manual
7-1
Options and Accessories
This section l i st s the standard and optional accessories available for the
TDS5000B Series oscilloscopes, as well as the product options.
Options
You can order the options shown in Table 7--1 with the oscilloscope.
Table 7- 1: Instrume nt options
Hardware options
18 Touch-screen in t erface
1P Built--in thermal printer (option not available for
instruments SN B030000 & above)
FHD Front panel removable hard drive
SM Serial communicat ions mask testing
Acquisi ti on memory options
3M 16M/8M/4M on 1/2/4 channels
Mounting options
1K K420 oscilloscope cart with mouse accessory tray
1R Rac k mount kit
Software options
DVD TDSDVD—Optical storage anal ys is software
J2 TDSDDM2—Disk drive measurements software
J3E TDSJIT3E—Jitter and timing analysis software
essentials
JT3 TDSJIT3—Jitter & timin g analysi s with Rj/Dj and
BER estimation
PW3 TDSPWR3—Power measurement software
USB TDSUSBS—USB2.0 compliance test software only
CP2 TDSCPM2—ANSI/ITU telecom pulse compl iance
software
ET3 TDSET3—Ethernet complianc e test software
Power cord options
A0 North American
A1 Universal European power cord (220 V, 50 Hz)
