Removal and Inst a l l a t i on Procedures
6-- 14
TDS5000B Series Se r vi c e Manual
1. Remove the bot t om covers: See Figure 6--3.
2. Orient the osci l l osc ope : Set the oscilloscope so the top is down on t he work
surface and t he bottom is facing you.
a. Remove the two T-15 TORX drive screws that secure the bottom
cosmetic cover to the osci l l osc ope , and remove the cover.
b. Re m ove the seven T-15 TORX drive screws that secure the bottom metal
cover to the oscilloscope, and remove the cover.
3. Reinstallation: Do in rever se steps a through b to reinstall t he bottom covers.
Be sure to properly locate the 5 black screws (if present; see Figure 6--3).
T-15 Black oxide TORX drive
screws (5). Note: Be sure to
reinstall these screws here.
Bottom cosmetic
cover
T-15 TORX drive
screw (4)
Bottom metal
cover
Figure 6--3: Bottom cover removal
Bottom Covers
