Tektronix TDS5000B Series

Removal and Inst a l l a t i on Procedures
TDS5000B Series Se r vi c e Manual
6-- 31
d. Re m ove the floppy drive from the bracket.
Floppy drive
bracket
Floppy drive
#0 Philli ps
screw (2)
Figure 6--16: Floppy disk dri v e removal
4. Reinstallation: Do in reverse st e ps a through d to reinst a l l the floppy disk
drive.
