TDS5000B Series Service Manual
2-1
Operating Information
This chapter covers installation information and basic operation instructions.
Installation
The basic operating software is already installed on the hard disk. Refer to
Software Installation on page 2--5 for instructions on reinstalling the software.
NOTE. To avoid rebuilding your hard disk, be sure to create an emergency
startup disk. You will need this disk if you ever have to reinstall the Windows
operating system. R efer to Create an Emergency Startup Disk on page 2--4.
Verify that all parts and accessories for the oscilloscope are available. Use the
graphical packing list that came with the oscilloscope to determine the necessary
parts and accessories. You should also verify that the following items are
available:
! The correct power cords
! The product-software CD set that includes installation copies of the software
installed on t he oscilloscope
! All the accessories necessary to operate the oscilloscope
The oscilloscope is designed to operate on a bench or on a cart in the normal
position (on the bottom feet). For proper cooling, at least three i nches (7. 62 cm)
of clearance is required on the left side of t he oscilloscope. If you operate the
oscilloscope while it is resting on the rear feet, make sure that you properly route
any cables coming out of the rear of the oscilloscope to avoid damaging them.
CAUTION. To prevent overheating the oscilloscope, keep the bottom and sides of
the oscilloscope clear of obstructions to ensure proper cooling.
Before You Start
Environmental
Considerations
