TDS5000B Series Service Manual
i
Table of Contents
General Safety Summary vii...................................
Service Safety Summary ix....................................
Envi ronmental Considerations xi...............................
Preface xiii...................................................
Manual Structure xii i................................................
Manual Conventions xii i..............................................
Related Documentati on xiv...........................................
Specifications
Operating Information
Instal lation 2--1.....................................................
Before You Start 2--1.............................................
Environmental Considerations 2--1..................................
Connec t the Peripherals 2--2........................................
Power On the Instrument 2--4.......................................
Powering Off the Oscilloscope 2--4..................................
Crea te an Emergency Startup Disk 2--4...............................
Software Installation 2--5..........................................
Operating Information 2--6............................................
Back Up User Files 2--6...........................................
User Interface Map 2--7...........................................
Front Panel I/O Map 2--8..........................................
Rea r Panel I/O Map 2--8...........................................
Front Panel Controls Map 2--9......................................
Instrume nt Diagnostics 2--10........................................
Signal Path Compensation 2--10.....................................
Using the Online Help 2--11.........................................
Theory of Operation
Logic Conventions 3--1...............................................
Module Overviews 3--1...............................................
To Next Page
