Tektronix TDS5000B Series

Removal and Inst a l l a t i on Procedures
6-- 34
TDS5000B Series Se r vi c e Manual
Hard drive
Hard drive
bracket
Screw (2)
From power
supply
Disconnect from
the hard drive
To
CDRW
drive
Hard drive
Motherboard
assembly
Disconnect from the hard drive
(SN B029999 and below)
(SN B030000 and above)
Figure 6--18: Desktop hard dri v e removal
