Removal and Inst a l l a t i on Procedures
TDS5000B Series Se r vi c e Manual
6-- 33
1. Locate module to be removed: Loca t e the Hard Disk Drive assembly in the
locator diagram Internal Modules, Fi gur e 6--7, page 6-- 19. Note the location
of cables a nd cable connector s see Figure 6--17 on page 6--32. Additional
modules to be removed:
! Trim (all exce pt front panel and acquisition)
! Right side cover
! Printer frame (SN B029999 and Below)
CAUTION. To prevent permanent damage to the hard disk drive, do not remove
the hard drive when the oscill osc ope is powered on.
Always power off the oscilloscope before removing the hard disk drive.
2. Orient the osci l l osc ope : Set the oscilloscope so the bottom i s down on the
work surface a nd the right side panel is facing you.
3. Remove the Hard Disk Drive assembly : See Figure 6--18, on page 6--34.
a. Verify that the oscilloscope is powered off.
b. Re m ove the 2 T-15 TORX sc r e ws that secure the Hard Disk Drive
assembly to the chassis.
c. Pull the Hard Disk Drive assembly away from the chassi s far enough to
access the c a bl e s.
d. Di sc onne c t the 2 cables from the Hard Di sk Drive assembly. See Figure
6-- 18 on page 6--34.
e. Remove the 2 T-15 TORX dr i ve screws that secure the hard drive
bracket to the the hard drive.
4. Reinstallation: Do in reverse steps a through e to reinstall the hard disk drive.
Hard Disk Drive
