Calibration Procedure
5-2
TDS5000B Series Service Manual
Table 5- 1: C a libration required for module
replaced (Cont.)
Module replaced Calibration required
Mi c ro ATX processor assem-
bly
No
Display panel o r display
system
No
Power supply No
Interconnect boards No
Fans No
The sample calibration procedure requires the specific test equipment and
materials listed in Table 5--2.
Table 5- 2: R e quir e d equipment and materials
Category Specific equipment required Quantity
Signal source Wavetek 9500 Oscilloscope Calibrator, with Option 100
(high-stability time base)
1ea
Wavetek 9520 or 9530 Standard Output Module 4ea
Instrument
controller
PC-compatible computer with National Instruments
GPIB Controller card and National Instruments NI-488.2
for Windows software, running Windows 95 or later.
The PC must support Visual Basic wi n 32 applicati o ns
and be able to provide a TekVisa supported GPIB
connection to the Wavetek 9500 as well as to the
TDS5000B oscilloscope
1ea
Te st software Calibratio n software such as the sample Visual B a s ic 6
program list ed later in this chapter
1ea
Te kVisa drivers. These are av a ilable on the TDS5000B
Application CD
1ea
GPIB cables GPIB cable, 1 m min imum len gth, Tektronix part number
002-0991-01 or similar
2ea
Required Equipment
