Tektronix TDS5000B Series

Removal and Inst a l l a t i on Procedures
TDS5000B Series Se r vi c e Manual
6-- 17
1. Remove the pri nt e r frame if installed: See Figure 6--6.
! CD-Rom Trim
! Right-side panel
! Printer or a c c e ssor y tray
! Top cover trim
! Top two rear feet
! Pouch
! Right-side cover
2. Orient the osci l l osc ope : Set the oscilloscope so the rear is on the work
surface and t he front of the oscilloscope is facing you.
a. Remove the four T-15 TORX drive screws that secure the printer frame
to the chassis.
b. Re m ove the two T-15 TORX drive screws that secure the cable restrai nt
to the printer frame.
c. Remove the printer frame from the chassis.
CAUTION. Take care not to bind or snag the covers on the oscilloscope internal
cabling as you remove or instal l components.
3. Reinstallation: Do in reverse st e ps a through c to rei nst a l l the cabinet covers.
Printer Frame
(SN B029999 and below)
