Tektronix TDS5000B Series

Mechanical Parts List
TDS5000B Series Service Manual
10- 5
Inner Panels
Fig. &
index
number
Tektronix part
number
Serial no.
effective
Serial no.
discont ’d
Qty Name & description
10--2--1 407--4822--XX 1 BRAC KET:VGA
--2 211--1050--XX B010100 B029999 8 SCREW,MACHINE:6--32 X 0.312 L,PNH,STL CAD,T15
--3 344--0591--XX B010100 B029999 1 CLIP,CABL E:0.050 AL,
--4 200--4865--XX B010100 B029999 1 COVER,TOP:PRINTER TRAY,0.050 AL
--5 211--0747--XX 1 SCREW,MACHINE; 6--32 X 0.188,PNH,STL,C DPL,T--15 TORX DR
-- 6
-- 6 a
390--1217--XX
200--5037--XX
B010100
B030000
B029999 1 CABINET,TOP:0.05 ALUMINUM
COVER ,TOP; 0.05 ALUMINUM
--7 211--1164--XX 6 SCREW,MACHINE:6--32 X 0.25 L,PNH,T15,BLACK OXIDE
--8 200--4641--XX 1 COVER:BOTTOM,AL
--9 200--4661--XX 1 COVER:BOTTOM,COSMETIC,0.040 AL,W/BLACK VINYL ONE SIDE
10 441--2226--XX
441--2376--XX
441--2491--XX
B010100
B020000
B030000
B019999
B029999 1
1
CH ASSIS ASSY; FOR ASHLAND MOTHER BOARD,0.050 AL W /BRACKETS & HARDWARE
CH ASSIS ASSY; FOR LACROSSE MOTHER BOAR D,0.050 AL W/ BRACKETS & HARDWARE
CH ASSIS ASSY; FOR TAPPEN MOTHER BOARD,0.050 AL W/BRACKETS & HARDWARE
