Service Manual Information
Table 1: 039-0185-xx μATX POST codes, (cont.)
Item no. Module
Displayed POST
code Description
Memory Test 52
Test all memor y of memory above 1 MB using Virtual 8086
mode, page mode, and clear the memory
Reserved 53
Reserved 54
CPU display
55
Detect CPU speed and display
CPU vendor specificversionstringandturnonallnecessary
CPU features
Reserved 56
PnP Init
57
Display PnP logo and PnP early init
Reserved 58
Setup Virus Protect
59
Setup virus protect according to Setup
Reserved 5A
Awdflash Load
5B
If required, will auto load Awdflash.exe in POST
Reserved
5C
Onboard I/O Init
5D
Initializing onboard super IO
Reserved 5E
Reserved 5F
Setup enable
60
Display setup message and enable setup functions
Reserved 61
Reserved 62
Initialize & Install Mouse
63
Detect if mouse is present
initialize mouse
install interrupt vectors
Reserved 64
PS2 Mouse special
65
Special treatment to PS2 Mouse port
Reserved 66
ACPI init
67
ACPI sub-system initializing
Reserved 68
Setup Cache Controller
69 Initialize cache controller
Reserved 6A
Setup Entering
6B
Enter setup check and auto-configuration check up
Reserved
6C
Initialize Floppy Drive &
Controller
6D
Initialize floppy disk drive controller and any drives.
Reserved 6E
FDD install 6F
Install FDD and setup BIOS data area parameters
12
Reserved 70
TDS5000B Read This First 21
