2.3 CONNECTIONS AND STARTUP
This Section presents the electrical (Section 2.3.1) and pneumatic (Section 2.3.2)
connections for setup and preparing for instrument operation.
2.3.1 ELECTRICAL CONNECTIONS
Note
To maintain compliance with EMC standards, cable must be no
longer than 3 meters for all I/O connections.
WARNING – Electrical Shock Hazard
• High Voltages are present inside the instrument’s case.
• Power connection must have functioning ground connection.
• Do not defeat the ground wire on power plug.
• Turn off instrument power before disconnecting or connecting
electrical subassemblies.
•
Do not operate with cover off.
CAUTION – Avoid Damage to the Instrument
Ensure that the AC power voltage matches the voltage indicated on
the instrument’s model/specs label before plugging it into line
power.
2.3.1.1 CONNECTING POWER
Attach the power cord between the instrument’s AC power connector and a power outlet
capable of carrying at least the rated current at your AC voltage range and ensure that it is
equipped with a functioning earth ground. It is important to adhere to all safety and
cautionary messages.
