TELEDYNE API T300M - Setup; Table 2-12. Utilities Submenu Descriptions; Utilities

083730300A DCN8101 Getting Started 63
2.4.5 UTILITIES
The Utilities menu has a variety of functions as described next in Table 2-12.
Table 2-12. Utilities Submenu Descriptions
UTILITIES
MENU
DESCRIPTION
Datalog View
Displays the data logs that were configured via the Setup>Data Logging menu. From this list
a log can be selected and filters applied to view the desired data. (For details on setting up
and running the Data Logger, see Section 2.5.1).
Alerts Log
Displays a history of alerts that are triggered by factory-defined and user-
defined Events,
such as warnings and alarms (See Section 2.5.2 for Events configuration).
USB Utilities
Serves multiple purposes using a flash drive connected to the instrument’s front panel USB
port:
• download data from the instrument’s Data Acquisition System (DAS), the Data Logger, to
a flash drive (Section 2.5.1.3)
• update firmware (Section 5.3)
• transfer instrument configuration from/to other same-model instruments (Section 2.6)
• download a basic operation functionality report (Section 5.3).
Diagnostics
Provides access to various pages that facilitate troubleshooting.
Analog Inputs Measure voltage signals
of several analog input parameters. These can
be logged in the internal data acquisition
system (DAS), by configuring
the Data Logger in the Setup>Data Logging menu (Section 2.5.1).
Analog Outputs Show the voltage signals for the functions selected and configured in the
Setup>Analog Outputs menu (Section 2.5.8).
Digital Inputs S
how whether specific available features are turned ON or OFF; for
example, whether or not Maintenance Mode input or Language selection
can be controlled through the front panel,
or whether a zero or span
calibration can be activated remotely when an external source is
connected to the rear panel Control In connector.
Digital Outputs Show the function of user-specified parameters
configured in the
Setup>Digital Outputs menu (Section 2.5.7).
Flow Cal Used to calibrate the sample gas flow reading with actual flow measured
by an external device. (See Section 4.5.3).
Dark Calibration Compensate for any voltage levels inherent in the s
ync/demod circuitry
that might affect the CO concentration calculation (Section 4.5.1).
Pressure Cal
Used for compensating for changes in atmospheric pressure
(Section 4.5.2).
2.4.6 SETUP
The Setup menu is used to conFigure the instrument’s various features, functions, and
data log. Section 2.5 provides details for the menus under Setup.
