User Manual for Oscar GNSS Receiver v2.4

Set Power: 0.5W(Low) /

1W(Medium) / 2W(High)

Set Channel: 0--9

Set Customize Freq.

External Radio

Set Serial Port Baud Rate:

9600/ 19200/ 38400/ 57600/

115200/ 460800

Set Data Speed (Full/ High/

Medium/ Low)

Set Format: RTCMv2.3/

RTCMv3 / RTCMv3.2/ RTD/

CMR

Rover Mode

TCS

(Tersus Caster Service)

Set Base ID: ********

Set Server

NTRIP Client

Check historical IP Address &

Port

TCP Client

Check History & Add Address

Internal Radio

Set Protocol: TRANSEOT/

TT450/ SOUTH/ SATEL/

TRIMMK3

Set Air-Baud-Rate: 9600/

19200/ 4800

Set Channel: 0--9

Set Customize Freq.

Single Mode

Confirm/ Cancel

Tilt.: ON/OFF

(Oscar Ultimate

only)

ON/OFF

Pole Height

Input Pole Height
