Texas Instruments C2000 Workshop Guide And Lab Manual

ePWM
7 - 10 C2000 Microcontroller Workshop - Control Peripherals
ePWM Time-Base Control Register
EPwmxRegs.TBCTL
Upper Register:
FREE_SOFT PHSDIR CLKDIV HSPCLKDIV
15 - 14 13 12 - 10 9 - 7
TBCLK = SYSCLKOUT / (HSPCLKDIV * CLKDIV)
TB Clock Prescale
000 = /1 (default)
001 = /2
010 = /4
011 = /8
100 = /16
101 = /32
110 = /64
111 = /128
High Speed TB
Clock Prescale
000 = /1
001 = /2 (default)
010 = /4
011 = /6
100 = /8
101 = /10
110 = /12
111 = /14
Emulation Halt Behavior
00 = stop after next CTR inc/dec
01 = stop when:
Up Mode; CTR = PRD
Down Mode; CTR = 0
Up/Down Mode; CTR = 0
1x = free run (do not stop)
Phase Direction
0 = count down after sync
1 = count up after sync
(HSPCLKDIV is for legacy compatibility)
ePWM Time-Base Control Register
EPwmxRegs.TBCTL
Lower Register:
CTRMODESWFSYNC SYNCOSEL PRDLD PHSEN
6 5 - 4 3 1 - 02
Software Force Sync Pulse
0 = no action
1 = force one-time sync
Sync Output Select
(source of EPWMxSYNC0 signal)
00 = EPWMxSYNCI
01 = CTR = 0
10 = CTR = CMPB
11 = disable SyncOut
Counter Mode
00 = count up
01 = count down
10 = count up and down
11 = stop – freeze (default)
Period Shadow Load
0 = load on CTR = 0
1 = load immediately
Phase Reg. Enable
0 = disable
1 = CTR = TBPHS on
EPWMxSYNCI signal
