Control Law Accelerator (CLA)
C2000 Microcontroller Workshop - Control Law Accelerator 10 - 15
CLA Task Assembly Code Example
.cdecls "Lab.h"
.sect "Cla1Prog"
_Cla1Prog_Start:
_Cla1Task1: ; FIR filter
MUI16TOF32 MR2, @_AdcResult.ADCRESULT0
MMPYF32 MR2, MR1, MR0
MADDF32 MR3, MR3, MR2
MF32TOUI16 MR2, MR3
MMOV16 @_ClaFilteredOutput, MR2
MSTOP ; End of task
;-------------------------------------
_Cla1Task2:
MSTOP
;-------------------------------------
_Cla1Task3:
MSTOP
ClaTasks.asm
 .cdecls directive used
to include the C
header file in the CLA
assembly file
 .sect directive used to
place CLA assembly
code in its own
section
 C Peripheral Register
Header File references
can be used in CLA
assembly code
 MSTOP instruction
used at the end of the
task
CLA Initialization Code Example
#include "F2806x_Cla_typedefs.h"
#include “F2806x_Device.h"
extern Uint16 Cla1Prog_Start;
extern interrupt void Cla1Task1();
extern interrupt void Cla1Task2();
extern interrupt void Cla1Task8();
Lab.h
#include "Lab.h"
// Symbols used to calculate vector address
Cla1Regs.MVECT1 =
(Uint16)((Uint32)&Cla1Task1 -
(Uint32)&Cla1Prog_Start);
Cla1Regs.MVECT2 =
(Uint16)((Uint32)&Cla1Task2 -
(Uint32)&Cla1Prog_Start);
Cla.c
 Defines data types and
special registers
specific to the CLA
 Defines register bit
field structures
 Symbol for start of CLA
program RAM defined
in Lab.cmd
 CLA task prototypes
are prefixed with the
‘interrupt’ keyword
 CLA task symbols are
visible to all C28x CPU
and CLA code
MVECTx contains the offset address from the start of the CLA Program RAM
