6. COORDINATE MEASUREMENT
6-6
13
Press [F3](YES) key. 4)
The instrument rotates and the
telescope turns to inverted position
automatically and the measurement of
the known point B starts. 3)
When the measurement of point B is
completed, the instrument rotates and
starts the measurement of known
point A in inverted position . 3)
When the measurement of known point
A is completed, the instrument rotates
and the telescope turns to the normal
position automatically .
Vertical angle error (dVA,dVB) and
horizontal angle discrepancy (dH) will
be displayed. 5)
[F3]
V : 269

39
'
15
"
HR : 250

30
'
40
"

POI
N
TB
(
2
)


CHEC
K
I
N
G


MEAS
U
RI
N
G

SET ! !
V: 269

49
'
50
"
HR : 190

20
'
35
"

POI
N
TA
(
2
)


CHEC
K
I
N
G


MEAS
U
RI
N
G

SET !!

RET
U
R
N
A

dVA: : 0

00
'
10
"
dVA: -0

00
'
15
"
dH: 0

00
'
05
"
SET O
K

[ YES ][ NO ]
14
Confirm the vertical angle error and
horizontal angle discrepancy and press
[F3](YES) key. 6)
Discrepancy (dHD) and discrepancy
(dZ) will be displayed. 7)
[F3] dHD & dZ
dHD: -0.0012 m
dZ: 0.0023 m
SET O
K

[ YES ][ NO ]
15
Confirm the discrepancy , and press
[F3](YES) key. 8)
The coordinate of the instrument point
will be displayed.
[F3]
N : 1.2345
E : 2.3456
Z : -3.4567
SET O
K

[ YES ][ NO ]
16
Confirm the coordinate of instrument
point , and press [F3](YES) key.
Setting coordinate value of the
instrument is completed, the display
returns to the previous measurement
mode . 9)
[F3]
V: 90

10 '20"
HR : 10

20' 30"
BS CSET RST 5

1) Selecting 2D, will be omitted following input of instrument height, Z-Coordinate value, and prism
height.
2) In order to set value of the instrument height, use the soft key (CSET).
