6. COORDINATE MEASUREMENT
6-10
17
Press [F3](SET) or (REC) key.
Measurement will be done 2 times.
Vertical angle error (dVA,dVB) and
horizontal angle discrepancy (dH) will
be displayed. *4)
[F3]
or
[REC]
V : 269
49
'
15
"
HR : 190
20
'
35
"
SD
MEASURI
G
SET ! !
dVA: : 0
00
'
10
"
dVA: -0
00
'
15
"
dH: 0
00
'
05
"
SET OK
[ YES ][ NO ]
18
Vertical angle error (dVA,dVB) and
horizontal angle discrepancy (dH) will
be displayed. *4)
[
]
19
Confirm the vertical angle error and
horizontal angle discrepancy, and
press[F3](YES)key. *5)
Discrepancy (dHD) and discrepancy
(dZ) will be displayed. *6)
[F3]
dHD & dZ
dHD: -0.0012 m
dZ: 0.0023 m
SET O
[ YES ][ NO ]
20
Confirm the value, and press
[F3](YES) key *7)
The coordinate value of instrument
point will be displayed.
[F3]
: : 1.2345
E : 2.3456
Z : 3.4567
SET OK
[ YES ][ NO ]
21
Confirm the value, and press [F3](YES)
key.
Setting the coordinate of instrument
point is completed, the display returns
to the previous measurement mode.
*8)
[F3]
V: 90
10
'
20
"
HR : 10
20
'
30
"
BS CSET RST 5
*1) Selecting 2D, will be omitted following input of instrument height, Z-Coordinate value, and prism
height.
*2) Use soft key (CSET) to set value of the instrument height.
*3) Press [F4](NO) key when the measurement by inverted position of telescope is not required,the
procedure goes to step
20
.
*4) Error message will be displayed when the vertical angle error or horizontal angle discrepancy is
exceeded 60", and returns to the procedure
automatically.
Vertical angle error (dVA) of the known point A
dVA = [Measured value in normal position] + [Measured value in inverted
position] 360 (at zenith)
Vertical angle error (dVB) of the known point B
dVB = [Measured value in normal position] + [Measured value in inverted
position] 360 (at zenith)
Horizontal angle discrepancy (dH)
dH = [Measured angle value between 2points in normal position]
[Measured angle value between 2point in inverted position]
*5) [F3](NO) key is pressed,the procedure returns to step
.
