15. SPECIAL MODE (MENU KEY OPERATION)
15-10
15.4 Setting Special Mode
[Example 1]: Search Pattern : High
Search Range : Horizontal angle 20, Vertical angle 10
Operating procedure Operating key Display
 Press [MENU] key from the distance or
angle display.
[MENU]
MENU 1/1
F1 : PARAMETERS
F2 : PROGRAMS
F3 : REMOTE
 Select [F1:PARAMETERS] [F1]
PARAMETERS 1/1
F1 : TRK
F2 : MEAS
F3 : COM
 Select [F1:TRK]
[F1]
TRK 1/3
F1 : SEARCH
F2 : WAIT TIME
F3 : SCAN WIDTH
 Select [F1:SEARCH] [F1]
SE ARCH P ATTE R
N
HIGH
EXIT


E
N
T
SET!!
 Select [F1:PATTERN].
 Select pattern by pressing [F2]()key
or [F3]()key, and press [ENT] key.
[Example] HIGH
[F1]
[F2]
or
[F3]
[ENT]
SE ARCH
F1 : PTTER
N
F2 : AREA
The display returns to search menu.
SEARCH
F1 : PATTERN
F2 : AREA
 Select [F2:AREA].
Displays current setting value. 1)
 Input Search range and press [ENT] key
[Example] H20,V10
[F2]
2
0
[ENT]
1
0
[ENT]
SEARCH SET HIGH
H: 20

V: 10

EXIT

CLR
 
SET!!
The display returns to search menu
after setting . 2)
SEARCH
F1 : PATTERN
F2 : AREA
1) To cancel setting , press [F1](EXIT) key or [ESC] key.
2) Pressing [ESC] key, returns to TRK-SET menu. Pressing [MENU] key, returns to normal mode.
