15. SPECIAL MODE (MENU KEY OPERATION)
15-11
[ Example 2]: To set transfer speed of 9600 baud rate for COM-1
Operating procedure Operating key Display
 Press [MENU] key from the distance or
angle display.
[MENU]
MENU 1/1
F1 : PARAMETERS
F2 : PROGRAMS
F3 : REMOTE
 Select [F1:PARAMETERS] [F1]
PARAMETERS 1/1
F1 : TRK
F2 : MEAS
F3 : COM
 Select [F3:COM]
[F3]
COM 1/2
F1 : COM1
F2 : COM2(REMOTE)
 Select [F1:COM1] [F1]
COM1
F1 : BIT FORMAT
F2 : TRANS SPEED
F3 : TERMINATE
 Select [F2:TRANS SPEED] 1)
[F2]
TRANSMIT SPEED 1
4800
EXIT

ENT
 Press [F2]()or [F3]() key and select
"9600".
 Press [F4](ENT) key
[F2]
or
[F3]
[F4]
TRANSMIT SPEED 1
9600
EXIT

ENT
SET !
COM1
F1 : BIT FORMAT
F2 : TRANS SPEED
F3 : TERMINATE
1) To cancel setting , press [ESC] key or [F1](EXIT) key.
2) Pressing [ESC] key, returns Menu mode, and pressing [MENU] key returns to normal mode.
