RemovingtheEngine(continued)
g401593
Figure17
1.Positive(+)batterycable
4.Wireharnessground
2.Machinewireharness5.Fusiblelinkharness
3.Negative(-)batterycable
11.Removethefastenersthatsecuretheenginetothechassis.
CAUTION
Useanappropriateliftandtheliftinglugsprovidedtopreventthe
enginefromfallingandcausingpersonalinjuryorproductdamage.
Theweightoftheengineisapproximately43kg(94lb).
12.Carefullyremovetheengineassemblyfromthemachine.
13.Draintheenginecrankcaseandremovetheoildrainvalveifnecessary.
InstallingtheEngine
RefertoFigure15forthisprocedure.
1.Ensurethatallpartsthatwereremovedfromtheengineduringmaintenance
areproperlyinstalled.Iftheoildrainvalvewasremovedfromtheengine,
installthedrainvalvengertightthentightenthevalveanadditional1-1/2
to2-1/2revolutions.
CAUTION
Useanappropriateliftandtheliftinglugsprovidedtopreventthe
enginefromfallingandcausingpersonalinjuryorproductdamage.
Theweightoftheengineisapproximately43kg(94lb).
