E6582062
5-29 5. [Fundamental operation] How to use parameters
3
4
5
9
■ Selecting a setting value
1: 50Hz setting
The following parameters are set for the base frequency 50 Hz.
Setting values of other parameters are not changed.
When you select a parameter and press the [OK] key, nothing appears momentarily, the same
content displayed at power on appears, and the mode enters [Standard mode].
<FH: Maximum frequency> 50Hz
<UL: Upper limit frequency>
*1 % display
<vL: Base frequency 1>
<F170: Base frequency 2>
<F174: Base frequency 3>
<F178: Base frequency 4>
<F204: RR point 2 frequency>
<F213: RX point 2 frequency>
<F219: II point 2 frequency>
<F225: AI4 point 2 frequency>
<F231: AI5 point 2 frequency>
<F237: S4/S5 Pulse train input point 2 frequency>
<F330: Light-load high-speed automatic operation
frequency>
<F355: Commercial power switching>
<F364: PID1 deviation upper-limit>
<F365: PID1 deviation lower-limit>
<F367: PID1 set value upper-limit>
<F370: PID1 output upper-limit>
<F426: Fwd speed limit level>
<F428: Rev speed limit level>
<F814: Communication point 2 frequency>
<A220: Pump increase detection frequency>
<A229: Pump decrease switching frequency>
<A230: PID start frequency at pump decrease
switching>
<A316: PID2 deviation upper-limit>
<A317: PID2 deviation lower-limit>
<A319: PID2 set value upper-limit>
<A322: PID2 output upper-limit>
<A538: PTI position frequency UL>
<F417: Motor rated speed>
1400 - 1480min
-1
(Depending on capacity)
