Toshiba TOSVERT VF-AS3 User Manual

E6582062
11. Table of parameters 11-6
1
9
11
11. 3 Extended parameter
Title
Communication
No.
Parameter name Adjustment range Unit
Minimum
setting unit
(Panel/
Communication)
Default
setting
Write
during
running
*6
User
setting
Reference
F100 0100
Low-speed signal
output frequency
0.0 - FH Hz 0.0 Y
[2. 4. 1]
[6. 1. 1]
F101 0101
Reach signal
specified frequency
0.0 - FH Hz 0.0 Y [6. 1. 3]
F102 0102
Reach signal
detection band
0.0 - FH Hz 2.5 Y
[6. 1. 2]
[6. 1. 3]
F105 0105
Fwd/Rev priority of
both close
0: Reverse
1: Stop
- - 1 N [6. 2. 1]
F107 0107
Terminal RX input
voltage select
0: 0 to +10 V
1: -10 to +10 V
--0N
[6. 2. 2]
[6. 6. 2]
[7. 3. 1]
[7. 3. 4]
F108 0108
Terminal RR input
select
1: Voltage input (0-10 V)
2: -
3: -
4: PTC input
5: PT100 (2-wire) input
6: -
7: PT1000 (2-wire) input
8: -
9: KTY84 input
--1N
[6. 2. 3]
[6. 6. 2]
[6. 30. 19]
F110 0110
Always active
function 1
0 - 177
*4
--6N
[6. 3. 1]
[7. 2. 1]

Toshiba TOSVERT VF-AS3 Specifications

General

Model	TOSVERT VF-AS3
Category	Inverter
Overload Capacity	150% for 60 seconds
Cooling Method	Forced Air Cooling
Control Method	V/f control, Sensorless vector control
Braking Unit	Built-in
Communication Protocols	Modbus RTU, DeviceNet, Profibus DP
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault
Enclosure	IP20
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
