6. [Advanced] How to use parameters 6-156
4
4
6
9
<F660: Override adding input select>
<F661: Override multiplying input select>
<F729: Panel override multiplication gain>
■ Function
You can make adjustment for adding or multiple to frequency command value by external signal.
■ Parameter setting
6. 32 Frequency adjustment using external
input (override function)
Title Parameter name Adjustment range Unit Default setting
F660 Override adding input
select
0: -
1: Terminal RR
2: Terminal RX
3: Terminal II
4: Terminal AI4 (option)
5: Terminal AI5 (option)
6 - 9: -
10: Touch wheel 1 (power off or press OK to
save)
11 - 14: -
15: Terminal Up/Down frequency
16: Pulse train
17: High resolution pulse train (option)
18/19: -
20: Embedded Ethernet
21: RS485 communication connector 1
22: RS485 communication connector 2
23: Communication option
0
F661 Override multiplying input
select
0: -
1: Terminal RR
2: Terminal RX
3: Terminal II
4: Terminal AI4 (option)
5 - 11: -
12: F729
13 - 30: -
31: Terminal RR
*1
32: Terminal RX
*1
33: Terminal II
*1
34: Terminal AI4 (option)
*1
35 - 41: -
42: F729
*1
0
1: Terminal RR
2: Terminal RX
3: Terminal Ⅱ
4: Terminal AI4(option)
0.0HzSTOP
14:07
0: -
F660 : Override adding input select
