8-1 8. Monitoring operation status
I
II
III
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
In [Monitor mode], the operation status of the inverter, ON/OFF information of input/output termi-
nals, trip record, etc. are displayed.
This chapter explains the display contents of [Monitor mode].
Furthermore, display at the time of occurrence of a trip and causes and remedies are also intro-
duced.
For the outline of screen display of [Monitor mode], refer to [3. 1. 2] "■Screen display of [Monitor mode]".
8. 1. 1 Operation Status monitor
When [Standard mode] is displayed on the LCD screen during run, press the [F4] key or press [ESC]
key twice to switch to [Monitor mode].
8
Monitoring operation status
8. 1 Screen display of [Monitor mode]
