11-69 11. Table of parameters
1
3
9
10
11
11. 11 Guidance function
Embedded Ethernet setting
<AUF>=1
C081-C096 Device name 1-16
C610 Emb Eth. IP setting mode
C611-C614 Emb Eth. IP address setting value
C615-C618 Emb Eth. Subnet mask setting value
C619-C622 Emb Eth. Default gateway setting
value
C629-C632 Emb Eth. IP address monitor
C633-C636 Emb Eth. Subnet mask monitor
C637-C640 Emb Eth. Default gateway monitor
Preset speed operation
<AUF>=2
CMOd Run command select
FMOd Frequency command select
ACC Acceleration time 1
dEC Deceleration time 1
FH Maximum frequency
UL Upper limit frequency
Sr1-Sr7 Preset speed 1-7
F111-F116 Terminal xx function
F287-F294 Preset speed 8-15
Analog frequency command
<AUF>=3
CMOd Command mode selection
FMOd Frequency mode selection
ACC Acceleration time 1
dEC Deceleration time 1
FH Maximum frequency
UL Upper limit frequency
LL Lower limit frequency
F201 RR point 1 input value
F202 RR point 1 frequency
F203 RR point 2 input value
F204 RR point 2 frequency
F216 II point 1 input value
F217 II point 1 frequency
F218 II point 2 input value
F219 II point 2 frequency
Motor 1,2 switching
<AUF>=4
vL Base frequency
vLv Base frequency voltage 1
vb Manual torque boost
tHrA
Motor overload protection current 1
ACC Acceleration time 1
dEC Deceleration time 1
F111-F116 Terminal xx function
F170 Base frequency 2
F171 Base frequency voltage 2
F172 Manual torque boost 2
F182
Motor overload protection current 2
F185 Stall prevention level 2
F415 Motor rated current
F500 Acceleration time 2
F501 Deceleration time 2
F601 Stall prevention level 1
Motor parameter
<AUF>=5
Pt V/f pattern
vL Base frequency
vLv Base frequency voltage 1
F405 Motor rated capacity
F415 Motor rated current
F417 Motor rated speed
F400 Offline auto-tuning
PM motor parameter
<AUF>=6
Pt Motor control type
vL Motor base frequency
vLv Motor nominal voltage
F400 Auto tuning
F402 Automatic torque boost
F405 Motor rated capacity
F415 Motor nominal current
F417 Motor nominal speed
F458 Current control P gain
F460 Speed loop P gain
F461 Speed loop I gain
F462 Load inertia
F910 Step-out detection current
F911 Step-out detection time
F912 Auto tune Lq axis
F913 Auto tune Ld axis
F914 Current stall prevention frequency
F915 Starting method
F916 Id current at starting
F917 Lq ratio at 100% load
F918 Lq ratio at 200% load
F919 Reluctance torque ratio

Toshiba TOSVERT VF-AS3 Specifications

General

Model	TOSVERT VF-AS3
Category	Inverter
Overload Capacity	150% for 60 seconds
Cooling Method	Forced Air Cooling
Control Method	V/f control, Sensorless vector control
Braking Unit	Built-in
Communication Protocols	Modbus RTU, DeviceNet, Profibus DP
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault
Enclosure	IP20
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
