E6582062
6. [Advanced] How to use parameters 6-16
4
4
6
9
<F170: Base frequency 2>
<F171: Base frequency voltage 2>
<F172: Manual torque boost 2>
<F174: Base frequency 3>
<F175: Base frequency voltage 3>
<F176: Manual torque boost 3>
<F178: Base frequency 4>
<F179: Base frequency voltage 4>
<F180: Manual torque boost 4>
<F182: Motor overload protection current 2>
<F183: Motor overload protection current 3>
<F184: Motor overload protection current 4>
■ Function
These parameters are used for setting when you want to switch up to four types of motors for an
inverter, or when you want to switch the motor V/f characteristics (four types) according to the
purpose or operation method.
V/f1 to V/f4 are switched by the input terminal signals.
■ Parameter setting
6. 4 Switching two to four types of motor
characteristics
Memo
•
<Pt: V/f Pattern> is
valid only for V/f1.When V/f2 to V/f4 are selected, V/f constant control is applied regardless of the setting of <Pt>.
•
Do not switch the motors when <Pt:
V/f Pattern> is set to "7" or "8".• For the parameters that are selected when V/f1 to V/f4 are switched, refer to the following table.
Title Parameter name Adjustment range Unit Default setting
F170 Base frequency 2 15.0-590.0 Hz
50.0/60.0
*1
F171 Base frequency voltage 2 240V class: 50-330V
480V class: 50-660V
V
*1
F172 Manual torque boost 2 0.00-30.00 %
*2
F174 Base frequency 3 15.0 - 590.0 Hz
50.0/60.0
*1
F175 Base frequency voltage 3 240V class: 50-330V
480V class: 50-660V
V
*1
0.0HzSTOP
12:49
F170 : Base frequency 2
Min: 15.0 Max: 590.0
X1000 X100 X10 X1
Hz
60.0
0.0HzSTOP
12:53
F171 : Base frequency voltage 2
Min: 50 Max: 660
X1000 X100 X10 X1
V
400
