Toshiba TOSVERT VF-AS3 - Analog Output;Monitor Output Function

E6582062
11. Table of parameters 11-56
1
9
11
11. 7 Analog output/Monitor output function
Option
No.
Communication No.
Function Display unit
Unit
(Communication)
Analog output
Monitor
output
0 FD00 FE00 Output frequency 0.1Hz 0.01Hz
1 FD02 FE02 Frequency command value 0.1Hz 0.01Hz
2 FD03 FE03 Output current 1%/<F701> setting 0.01%
3 FD04 FE04 Input voltage (DC detection) 1%/<F701> setting 0.01%
4 FD05 FE05 Output voltage 1%/<F701> setting 0.01%
5 FD15 FE15 Stator frequency 0.1Hz 0.01Hz
6 FD16 FE16 Speed feedback frequency (real time) 0.1Hz 0.01Hz
7 FD17 FE17 Speed feedback frequency (1-second filter) 0.1Hz 0.01Hz
8 FD18 FE18 Torque 1% 0.01%
9 FD19 FE19 Torque command 1% 0.01%
10 FD99 FE99
Output frequency during run.
Frequency command value during stop.
Hz/free unit -
11 FD20 FE20 Torque current 1% 0.01%
12 FD21 FE21 Exciting current 1% 0.01%
13 FD22 FE22 PID feedback value 0.1Hz 0.01Hz
14 FD23 FE23 Motor overload factor (OL2 data) 1% 0.01%
15 FD24 FE24 Inverter overload factor (OL1 data) 1% 0.01%
16 FD25 FE25 Braking resistor overload factor (OLr data) 1% 1%
17 FD28 FE28 Braking resistor load factor (%ED) 1% 1%
18 DF29 FE29 Input power 0.1kW 0.01kW
19 FD30 FE30 Output power 0.1kW 0.01kW
20 FE76 FE76 Input cumulative power <F749> setting <F749> setting
21 FE77 FE77 Output cumulative power <F749> setting <F749> setting
22 Fixed output 1 - -
23 Fixed output 2 - -
24 FE35 FE35 Terminal RR input value 1% 0.01%
25 FE36 FE36 Terminal RX input value 1% 0.01%
26 FE37 FE37 Terminal II input value 1% 0.01%
27 FD94 FE94 Motor speed command *4 1 1
28 FE40 FE40 Terminal FM output value *1 1 0.01
29 FE41 FE41 Terminal AM output value *2 1 0.01
31 FA51 FA51 Communication data output *3 *3
32 FE66 Slot A option CPU version - -
33 FE67 Slot B option CPU version - -
34 FD26 FE26 Motor load factor % -
35 FD27 FE27 Inverter load factor % -
36 FE70 Inverter rated current A -
37 FD70
Inverter rated current (with carrier frequency
correction )
A-
