Toshiba TOSVERT VF-AS3 User Manual

E6582062
11-55 11. Table of parameters
1
3
9
10
11
Voltage
class
Applicabl
e motor
(kW)
Inverter
type-form
F412
(%)
F415
F416
(%)
F417
F456 F749
50Hz setting 60Hz setting
Adjustment
range
(A) (min-1)
3-phase
240 V
0.75
VFAS3-
2004P 7.0 0.01-99.99 3.40 55 1440 1730 100 0
1.5 2007P 5.0 0.01-99.99 6.40 42 1445 1740 100 0
2.2 2015P 5.0 0.01-99.99 9.40 50 1460 1755 100 0
4.0 2022P 5.0 0.01-99.99 14.60 38 1460 1755 100 0
5.5 2037P 5.0 0.01-99.99 21.40 41 1465 1760 100 1
7.5 2055P 5.0 0.01-99.99 28.60 38 1460 1755 100 1
11 2075P 4.0 0.01-99.99 42.00 38 1475 1770 100 1
15 2110P 4.0 0.01-99.99 55.60 33 1470 1760 100 1
18.5 2150P 4.0 0.01-99.99 69.00 37 1475 1770 100 1
22 2185P 4.0 0.1-999.9 80.0 32 1470 1760 100 1
30 2220P 4.0 0.1-999.9 108.0 33 1470 1765 100 1
37 2300P 4.0 0.1-999.9 132.0 32 1480 1775 100 1
45 2370P 3.0 0.1-999.9 159.0 31 1480 1775 100 2
55 2450P 3.0 0.1-999.9 192.0 28 1480 1775 100 2
75 2550P 3.0 0.1-999.9 264.0 28 1480 1775 100 2
3-phase
480 V
0.75
VFAS3-
4004PC 7.0 0.01-99.99 1.70 55 1440 1730 100 0
1.5 4007PC 5.0 0.01-99.99 3.20 42 1445 1740 100 0
2.2 4015PC 5.0 0.01-99.99 4.70 50 1460 1755 100 0
4.0 4022PC 5.0 0.01-99.99 7.30 38 1460 1755 100 0
5.5 4037PC 5.0 0.01-99.99 10.70 41 1465 1760 100 1
7.5 4055PC 5.0 0.01-99.99 14.30 38 1460 1755 100 1
11 4075PC 4.0 0.01-99.99 21.00 38 1475 1770 100 1
15 4110PC 4.0 0.01-99.99 27.80 33 1470 1760 100 1
18.5 4150PC 4.0 0.01-99.99 34.50 37 1475 1770 100 1
22 4185PC 4.0 0.01-99.99 40.00 32 1470 1760 100 1
30 4220PC 4.0 0.01-99.99 54.00 33 1470 1765 85 1
37 4300PC 4.0 0.01-99.99 66.00 32 1480 1775 80 1
45 4370PC 3.0 0.1-999.9 79.5 31 1480 1775 100 2
55 4450PC 3.0 0.1-999.9 96.0 28 1480 1775 100 2
75 4550PC 3.0 0.1-999.9 129.0 28 1480 1775 100 2
90 4750PC 3.0 0.1-999.9 154.0 26 1480 1775 80 2
110 4900PC 3.0 0.1-999.9 190.0 21 1480 1780 100 2
132 4110KPC 3.0 0.1-999.9 230.0 20 1485 1780 100 2
160 4132KPC 3.0 0.1-999.9 252.0 20 1485 1785 100 2
220 4160KPC 3.0 0.1-999.9 315.0 20 1485 1785 100 2
250 4200KPC 3.0 0.1-999.9 345.0 20 1485 1785 100 2
280 4220KPC 3.0 0.1-999.9 445.0 20 1485 1785 100 2
315 4280KPC 3.0 0.1-999.9 544.0 20 1485 1785 100 2

Toshiba TOSVERT VF-AS3 Specifications

General

Model	TOSVERT VF-AS3
Category	Inverter
Overload Capacity	150% for 60 seconds
Cooling Method	Forced Air Cooling
Control Method	V/f control, Sensorless vector control
Braking Unit	Built-in
Communication Protocols	Modbus RTU, DeviceNet, Profibus DP
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault
Enclosure	IP20
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
