Toshiba TOSVERT VF-AS3 User Manual

E6582062
11. Table of parameters 11-54
1
9
11
Voltage
class
Applicable
motor
(kW)
Inverter
type-form
F300
F308
(Ohm)
F309
(kW)
F316
F356
(s)
F402
(%)
F405
<Set> =" JP"
(kW)
other
(kW)
Adjustment
range
(kHz)
3-phase
240 V
0.75
VFAS3-
2004P 1.0-16.0 4.0 200.0 0.12 1 0.57 4.30 0.75 0.75
1.5 2007P 1.0-16.0 4.0 75.0 0.12 1 0.57 4.40 1.50 1.50
2.2 2015P 1.0-16.0 4.0 75.0 0.12 1 0.57 2.90 2.20 2.20
4.0 2022P 1.0-16.0 4.0 40.0 0.12 1 0.67 2.80 3.70 4.00
5.5 2037P 1.0-16.0 4.0 20.0 0.24 1 0.87 2.30 5.50 5.50
7.5 2055P 1.0-16.0 4.0 15.0 0.44 1 0.87 2.00 7.50 7.50
11 2075P 1.0-16.0 4.0 10.0 0.66 1 1.07 1.60 11.00 11.00
15 2110P 1.0-16.0 4.0 7.5 0.88 1 1.07 1.50 15.00 15.00
18.5 2150P 1.0-16.0 4.0 7.5 0.88 1 1.37 1.40 18.50 18.50
22 2185P 1.0-16.0 4.0 3.3 1.76 1 1.37 1.60 22.00 22.00
30 2220P 1.0-8.0 4.0 3.3 1.76 1 1.37 1.20 30.00 30.00
37 2300P 1.0-8.0 4.0 2.0 2.20 1 1.37 0.80 37.00 37.00
45 2370P 1.0-8.0 4.0 2.0 2.20 1 1.37 0.70 45.00 45.00
55 2450P 1.0-8.0 2.5 2.0 2.20 1 1.37 0.80 55.00 55.00
75 2550P 1.0-8.0 2.5 1.7 3.40 1 1.37 1.30 75.00 75.00
3-phase
480 V
0.75
VFAS3-
4004PC 1.0-16.0 4.0 200.0 0.12 3 0.57 4.30 0.75 0.75
1.5 4007PC 1.0-16.0 4.0 200.0 0.12 3 0.57 4.40 1.50 1.50
2.2 4015PC 1.0-16.0 4.0 200.0 0.12 3 0.57 2.90 2.20 2.20
4.0 4022PC 1.0-16.0 4.0 160.0 0.12 3 0.67 2.80 3.70 4.00
5.5 4037PC 1.0-16.0 4.0 80.0 0.24 3 0.87 2.30 5.50 5.50
7.5 4055PC 1.0-16.0 4.0 60.0 0.44 3 0.87 2.00 7.50 7.50
11 4075PC 1.0-16.0 4.0 40.0 0.66 3 1.07 1.60 11.00 11.00
15 4110PC 1.0-16.0 4.0 30.0 0.88 3 1.07 1.50 15.00 15.00
18.5 4150PC 1.0-16.0 4.0 30.0 0.88 3 1.37 1.40 18.50 18.50
22 4185PC 1.0-16.0 4.0 15.0 1.76 3 1.37 1.60 22.00 22.00
30 4220PC 1.0-16.0 4.0 15.0 1.76 3 1.37 1.20 30.00 30.00
37 4300PC 1.0-16.0 4.0 8.0 1.76 3 1.37 0.80 37.00 37.00
45 4370PC 1.0-16.0 4.0 8.0 1.76 3 1.37 0.70 45.00 45.00
55 4450PC 1.0-8.0 4.0 8.0 1.76 3 1.37 0.80 55.00 55.00
75 4550PC 1.0-8.0 4.0 8.0 1.76 3 1.37 1.30 75.00 75.00
90 4750PC 1.0-8.0 4.0 3.7 7.40 3 1.37 1.20 90.00 90.00
110 4900PC 1.0-8.0 2.5 3.7 7.40 3 1.37 0.90 110.0 110.0
132 4110KPC 1.0-8.0 2.5 3.7 7.40 3 1.37 0.80 132.0 132.0
160 4132KPC 1.0-8.0 2.5 3.7 7.40 3 1.37 0.80 160.0 160.0
220 4160KPC 1.0-8.0 2.5 1.9 8.70 3 1.37 0.80 220.0 220.0
250 4200KPC 1.0-8.0 2.5 1.9 8.70 3 1.37 0.80 250.0 250.0
280 4220KPC 1.0-8.0 2.5 1.4 14.00 3 1.37 0.80 280.0 280.0
315 4280KPC 1.0-8.0 2.5 1.4 14.00 3 1.37 0.60 315.0 315.0

Toshiba TOSVERT VF-AS3 Specifications

General

Model	TOSVERT VF-AS3
Category	Inverter
Overload Capacity	150% for 60 seconds
Cooling Method	Forced Air Cooling
Control Method	V/f control, Sensorless vector control
Braking Unit	Built-in
Communication Protocols	Modbus RTU, DeviceNet, Profibus DP
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault
Enclosure	IP20
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
