Toshiba TOSVERT VF-AS3 User Manual

E6582062
11-53 11. Table of parameters
1
3
9
10
11
■ ND rating
Voltage
class
Applicabl
e motor
(kW)
Inverter
type-form
vb,F172,F1
76,F180
(%)
ACC,dEC,F500,F5
01,F510,F511,F51
4,F515
(s)
tHrA,F182,F183,F184
F249
(kHz)
F298
(V)
Adjustment
range
(A)
3-phase
240 V
0.75
VFAS3-
2004P 4.80 10.0 0.46-4.60
4.60 4.0 120.0
1.5 2007P 4.80 10.0 0.80-8.00
8.00 4.0 120.0
2.2 2015P 3.10 10.0 1.12-11.20 11.20 4.0 120.0
4.0 2022P 3.10 10.0 1.87-18.70 18.70 4.0 120.0
5.5 2037P 2.50 10.0 2.54-25.40 25.40 4.0 120.0
7.5 2055P 2.30 10.0 3.27-32.70 32.70 4.0 120.0
11 2075P 1.80 10.0 4.68-46.80 46.80 4.0 120.0
15 2110P 1.60 10.0 6.34-63.40 63.40 4.0 120.0
18.5 2150P 1.50 30.0 7.84-78.40 78.40 4.0 120.0
22 2185P 1.70 30.0 9.3-92.6 92.6 4.0 120.0
30 2220P 1.40 30.0 12.3-123.0 123.0 4.0 120.0
37 2300P 0.90 30.0 14.9-149.0 149.0 4.0 120.0
45 2370P 0.80 30.0 17.6-176.0 176.0 4.0 120.0
55 2450P 0.80 30.0 21.1-211.0 211.0 2.5 120.0
75 2550P 1.40 60.0 28.2-282.0 282.0 2.5 120.0
3-phase
480 V
0.75
VFAS3-
4004PC 4.80 10.0 0.22-2.20
2.20 4.0 240.0
1.5 4007PC 4.80 10.0 0.40-4.00
4.00 4.0 240.0
2.2 4015PC 3.10 10.0 0.56-5.60
5.60 4.0 240.0
4.0 4022PC 3.10 10.0 0.93-9.30 9.30 4.0 240.0
5.5 4037PC 2.50 10.0 1.27-12.70 12.70 4.0 240.0
7.5 4055PC 2.30 10.0 1.65-16.50 16.50 4.0 240.0
11 4075PC 1.80 10.0 2.35-23.50 23.50 4.0 240.0
15 4110PC 1.60 10.0 3.17-31.70 31.70 4.0 240.0
18.5 4150PC 1.50 30.0 3.92-39.20 39.20 4.0 240.0
22 4185PC 1.70 30.0 4.63-46.30 46.30 4.0 240.0
30 4220PC 1.40 30.0 6.15-61.50 61.50 4.0 264.0
37 4300PC 0.90 30.0 7.45-74.50 74.50 4.0 264.0
45 4370PC 0.80 30.0 8.8-88.0 88.0 4.0 264.0
55 4450PC 0.80 30.0 10.6-106.0 106.0 4.0 264.0
75 4550PC 1.40 60.0 14.5-145.0 145.0 4.0 264.0
90 4750PC 1.30 60.0 17.3-173.0 173.0 4.0 264.0
110 4900PC 1.00 60.0 21.1-211.0 211.0 2.5 240.0
132 4110KPC 0.80 60.0 25.0-250.0 250.0 2.5 240.0
160 4132KPC 0.80 60.0 31.4-302.0 302.0 2.5 240.0
220 4160KPC 0.80 60.0 38.7-427.0 427.0 2.5 240.0
250 4200KPC 0.80 60.0 42.7-481.0 481.0 2.5 240.0
280 4220KPC 0.80 60.0 55.0-550.0
550.0 2.5 240.0
315 4280KPC 0.60 60.0 61.6-616.0
616.0 2.5 240.0

Toshiba TOSVERT VF-AS3 Specifications

General

Model	TOSVERT VF-AS3
Category	Inverter
Overload Capacity	150% for 60 seconds
Cooling Method	Forced Air Cooling
Control Method	V/f control, Sensorless vector control
Braking Unit	Built-in
Communication Protocols	Modbus RTU, DeviceNet, Profibus DP
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault
Enclosure	IP20
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
