E6582062
6. [Advanced] How to use parameters 6-114
4
4
6
9
<F520: Pattern operation>
<F521: Pattern operation continue select>
<F522: Pattern 1 repeat number>
<F523: Pattern 1 select 1> to <F530: Pattern 1 select 8>
<F531: Pattern 2 repeat number>
<F532: Pattern 2 select 1> to <F539: Pattern 2 select 8>
<F540: Operation time (1-speed)> to <F554: Operation time
(15-speed)>
■ Function
You can perform terminal run according to up to 30 types (15 types x 2 patterns) of operation
frequencies, operation time, and acceleration/deceleration time that were set in advance.
Pattern operation switching, and Run/Stop are all input from the terminals.
■ Parameter setting
6. 28 Pattern operation
Title Parameter name Adjustment range Unit Default setting
F520 Pattern operation 0: Disabled
1: Enabled (seconds)
2: Enabled (minutes)
0
F521 Pattern operation
continue select
0: Reset after stop
1: Continue after stop
0
F522 Pattern 1 repeat number 1-254
255: Continuous
Times 1
F523-F530 Pattern 1 select 1-8 0: Skip
1: Sr1
2: Sr2
3: Sr3
4: Sr4
5: Sr5
6: Sr6
7: Sr7
8: F287
9: F288
10: F289
11: F290
12: F291
13: F292
14: F293
15: F294
0
F531 Pattern 2 repeat number 1-254
255: Continuous
Times 1
F532-F539 Pattern 2 select 1-8 Same as <F523> 0
F540-F554 Operation time
(1 to 15-speed)
0.1-5999
6000: Continuous
The
unit is
set at
<F
520>.
5.0
0.0HzSTOP
13:52
F520 : Pattern operation
0: Disabled
1: Enabled (seconds)
2: Enabled (minutes)
To Next Page
