Toshiba TOSVERT VF-AS3 User Manual

E6582062
6-113 6. [Advanced] How to use parameters
3
4
6
9
■ Acc/Dec patterns
You can individually select Acc/Dec patterns by selecting Acc/Dec 1, 2, 3 or 4.
For details on the Acc/Dec patterns, refer to [6. 27. 1].
Parameters to determine S-Pattern ranges of "1: S-Pattern 1", <F506><F507><F508><F509>, is
common to Acc/Dec patterns 1 - 4.
Title Parameter name Adjustment range Unit Default setting
F502 Acc/Dec pattern 1 0: Linear
1: S-Pattern 1
2: S-Pattern 2
0
F503 Acc/Dec pattern 2 0
F512 Acc/Dec pattern 3 0
F516 Acc/Dec pattern 4 0
F506 S-Pattern range at Acc
start
0-50 % 10
F507 S-Pattern range at Acc
completion
0-50 % 10
F508 S-Pattern range at Dec
completion
0-50 % 10
F509 S-Pattern range at Dec
start
0-50 % 10
Reference
• How to operate the operation panel -> Refer to [3. 1. 1].
• How to switch display mode on the operation panel -> Refer to [3. 1. 2].
• Procedure to change parameter setting -> Refer to [4. 2. 3]
• Details on operation by external signals -> Refer to [Chapter 7].

Toshiba TOSVERT VF-AS3 Specifications

General

Model	TOSVERT VF-AS3
Category	Inverter
Overload Capacity	150% for 60 seconds
Cooling Method	Forced Air Cooling
Control Method	V/f control, Sensorless vector control
Braking Unit	Built-in
Communication Protocols	Modbus RTU, DeviceNet, Profibus DP
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault
Enclosure	IP20
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
