Toshiba TOSVERT VF-AS3 User Manual

E6582062
11-57 11. Table of parameters
1
3
9
10
11
38 FD81 Actual carrier frequency kHz -
39 FE68 Slot C option CPU version - -
40 FE91 Embedded Ethernet CPU version - -
41 FD43 FD43 Terminal FP pulse train output value pps -
43 FM/F671 Terminal FM/AM gain setting value - -
44 FE38 FE38 Terminal AI4 input value 1% 0.01%
45 FE39 FE39 Terminal AI5 input value 1% 0.01%
46 FE60 FE60 My function monitor output 1 - -
47 FE61 FE61 My function monitor output 2 - -
48 FE62 FE62 My function monitor output 3 - -
49 FE63 FE63 My function monitor output 4 - -
62 FD48 FE48 PID result frequency 0.1Hz 0.01Hz
63 FD58 FE58 PID set value 0.1Hz 0.01Hz
64 FD50 FD50 Light-load high-speed switching load torque 1% 0.01%
65 FD51 FD51
Light-load high-speed torque during constant
speed run
1% 0.01%
66 FE31 Pattern operation group number 0.1 0.1
67 FE32 Pattern operation remaining cycle number 1 1
68 FE33 Pattern operation preset speed number 1 1
69 FE34 Pattern operation remaining time 0.1 0.1
70 FE71 Inverter rated voltage 1 0.1
71 FD90 FE90 Motor speed (estimated value) *4 1 1
72 FA15 Communication option Receiving counter 1 1
73 FA16 Communication option Abnormal counter 1 1
76 FE56 FE56 Terminal S4/S5 pulse train input value 0.001 0.0001
77 FD85 My function COUNT1 1 1
78 FD86 My function COUNT2 1 1
79 FD87 FD87 Dancer control PID result frequency 0.1Hz 0.01Hz
80 FA25 Embedded Ethernet Transmission counter 1 1
81 FA17 Embedded Ethernet Receiving counter 1 1
82 FA18 Embedded Ethernet Abnormal counter 1 1
83 FE81 Connected option number 1 1
84 FD91 My function COUNT3 1 1
85 FD92 My function COUNT4 1 1
86 FD93 My function COUNT5 1 1
90 FE80 Cumulative power ON time 100 hours -
91 FD41 Cumulative cooling fan run time 100 hours -
92 FD14 Cumulative run time 100 hours -
93 FD31 Cumulative overcurrent time - -
95 E960 Pump 0 run time 100 hours -
96 E961 Pump 1 run time 100 hours -
97 E962 Pump 2 run time 100 hours -
Option
No.
Communication No.
Function Display unit
Unit
(Communication)
Analog output
Monitor
output

Toshiba TOSVERT VF-AS3 Specifications

General

Model	TOSVERT VF-AS3
Category	Inverter
Overload Capacity	150% for 60 seconds
Cooling Method	Forced Air Cooling
Control Method	V/f control, Sensorless vector control
Braking Unit	Built-in
Communication Protocols	Modbus RTU, DeviceNet, Profibus DP
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault
Enclosure	IP20
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
