Toshiba TOSVERT VF-AS3 User Manual

E6582062
11. Table of parameters 11-58
1
9
11
*1 Disabled with <FMSL: Terminal FM function>.
*2 Disabled with <F670: Terminal AM function>.
*3 For details, refer to RS485 Communication Function Instruction Manual (Exxxxxxx).
*4 Monitor is limited from -32700 to 32700.
*5 FD00(FE00), FD02(FE02), FD15(FE15), FD16(FE16), FD17(FE17), FD22(EF22) are unsigned value.
Internal polarity is used for signed analog output or monitor.
98 E963 Pump 3 run time 100 hours -
99 E964 Pump 4 run time 100 hours -
100 FD32 Number of starting 10000 times -
101 FD33 Number of Fwd starting 10000 times -
102 FD34 Number of Rev starting 10000 times -
103 FE59 External equipment counter Times -
105 E965 Pump 5 run time 100 hours -
106 E966 Pump 6 run time 100 hours -
107 E967 Pump 7 run time 100 hours -
108 E968 Pump 8 run time 100 hours -
109 E969 Pump 9 run time 100 hours -
110 FD35 Number of trip Times -
111 FD36 Number of serious failure trip Times -
112 FD37 Number of slight failure trip Times -
113 FD38 Number of specified trip 1 Times -
114 FD39 Number of specified trip 2 Times -
115 FD40 Number of specified trip 3 Times -
120 FD83 FE83 Internal temperature 1 - -
124 FE78 FE78 Power circuit board temperature - -
130 FD96 FD96 External PID3 set value - -
131 FD97 FD97 External PID3 feedback value - -
132 FD98 FD98 External PID3 result value - -
133 FE96 FE96 External PID4 set value - -
134 FE97 FE97 External PID4 feedback value - -
135 FE98 FE98 External PID4 result value - -
150 FD00 *5 FE00 Signed output frequency 0.1Hz 0.01Hz
151 FD02 *5 FE02 Signed frequency command value 0.1Hz 0.01Hz
152 FD15 *5 FE15 Signed stator frequency 0.1Hz 0.01Hz
153 FD16 *5 FE16 Signed speed feedback frequency (real time) 0.1Hz 0.01Hz
154 FD17 *5 FE17 Signed speed feedback frequency (1-second filter) 0.1Hz 0.01Hz
155 FD18 FE18 Signed torque 1% 0.01%
156 FD19 FE19 Signed torque command 1% 0.01%
158 FD20 FE20 Signed torque current 1% 0.01%
159 FD22 *5 FE22 Signed PID feedback value 0.1Hz 0.01Hz
160 FE37 FE37 Signed terminal RX input value 1% 0.01%
161 FE38 FE38 Signed terminal AI4 input value 1% 0.01%
162 FE39 FE39 Signed terminal AI5 input value 1% 0.01%
Option
No.
Communication No.
Function Display unit
Unit
(Communication)
Analog output
Monitor
output

Toshiba TOSVERT VF-AS3 Specifications

General

Model	TOSVERT VF-AS3
Category	Inverter
Overload Capacity	150% for 60 seconds
Cooling Method	Forced Air Cooling
Control Method	V/f control, Sensorless vector control
Braking Unit	Built-in
Communication Protocols	Modbus RTU, DeviceNet, Profibus DP
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault
Enclosure	IP20
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
