6-9 6. [Advanced] How to use parameters
3
4
6
9
6. 2. 2 Selecting input voltage of the terminal [RX]
<F107: Terminal RX input voltage select>
■ Function
This parameter selects the input voltage of the terminal [RX].
■ Parameter setting
■ Difference between the settings
0: 0 to +10 V
Input 0 to 10 Vdc between the terminals [RX]-[CC].
The resolution is 1/1000 at the maximum at 0 to 10 Vdc.
1: -10 to +10 V
Input -10 to +10 Vdc between the terminals [RX]-[CC].
The resolution is 1/2000 at the maximum at -10 to +10 Vdc.
Title Parameter name Adjustment range Default setting
F107 Terminal RX input
voltage select
0: 0 to +10 V
1: -10 to +10 V
0
Reference
• How to operate the operation panel -> Refer to [3. 1. 1].
• How to switch display mode on the operation panel -> Refer to [3. 1. 2].
• Procedure to change parameter setting -> Refer to [4. 2. 3]
• Details on operation by external signals -> Refer to [Chapter 7].
0: 0 to +10V
1: -10 〜 +10V
0.0HzSTOP
12:45
F107 : Terminal RX input voltage select

Toshiba TOSVERT VF-AS3 Specifications

General

Model	TOSVERT VF-AS3
Category	Inverter
Overload Capacity	150% for 60 seconds
Cooling Method	Forced Air Cooling
Control Method	V/f control, Sensorless vector control
Braking Unit	Built-in
Communication Protocols	Modbus RTU, DeviceNet, Profibus DP
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault
Enclosure	IP20
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
