6. [Advanced] How to use parameters 6-10
4
4
6
9
6. 2. 3 Selecting input signal of the terminal [RR]
<F108: Terminal RR input select>
■ Function
This parameter selects the input signal of the terminal
[RR].
■ Parameter setting
Title Parameter name Adjustment range Default setting
F108 Terminal RR input select 1: Voltage input (0-10 V)
2, 3: -
4: PTC input
5: PT100 (2-wire) input
6: -
7: PT1000 (2-wire) input
8: -
9: KTY84 input
1
Reference
• How to operate the operation panel -> Refer to [3. 1. 1].
• How to switch display mode on the operation panel -> Refer to [3. 1. 2].
• Procedure to change parameter setting -> Refer to [4. 2. 3]
1: Voltage input (0-10V)
2: -
3: -
4: PTC input
5: PT100(2-wire)input
0.0HzSTOP
12:46
F108 : Terminal RR input select

Toshiba TOSVERT VF-AS3 Specifications

General

Model	TOSVERT VF-AS3
Category	Inverter
Overload Capacity	150% for 60 seconds
Cooling Method	Forced Air Cooling
Control Method	V/f control, Sensorless vector control
Braking Unit	Built-in
Communication Protocols	Modbus RTU, DeviceNet, Profibus DP
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault
Enclosure	IP20
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
