6-151 6. [Advanced] How to use parameters
3
4
6
9
6. 30. 21 Setting number of starting alarm and alarm
occurrence of the specified trip
<F648: Number of starting alarm>
<F658: Number of external equipment starting alarm>
<F664: Specified trip 1>
<F665: Specified trip 2>
<F666: Specified trip 3>
■ Function
This parameter counts the number of starting of the inverter, and when it reaches the value set by
<F648: Number of starting alarm>, it outputs the alarm and confirm it in [Monitor mode].
For number of external equipment starting alarm, you can outputs the alarm and confirm it in
[Monitor mode]. For number of starting for external equipment, the number of input to the input
terminal is counted.
Also, occurrence of the specified trip can be confirmed in [Monitor mode].
■ Parameter setting
■ Signal output of the number of starting alarm of the inverter
This parameter counts the number of starting of the inverter, and when it reaches the value set by
<F648: Number of starting alarm>, it outputs the alarm and confirm it in [Monitor mode].
Output alarm
Assign "162: Number of starting alarm" to the unused output terminal. For details, refer to [7. 2. 2].
[Monitor mode]
Set "100: Number of starting" to <F711: Monitor mode 1 display> through <F718: Monitor mode 8
display>. For details, refer to [8. 1. 1].
■ Signal output of the number of external equipment starting alarm
This parameter counts the number of starting of the external equipment, and when it reaches the
values set by <F658: Number of external equipment starting alarm>, it outputs the alarm and can be
confirmed in [Monitor mode].
For Number of starting for external equipment, a signal to the input terminal with the function of "114:
External equipment counter" is assigned is counted.
Output alarm
Title Parameter name Adjustment range Unit Default setting
F648 Number of starting alarm 0 - 999.0 x10,000 times 999.0
F658 Number of external
equipment starting alarm
0 - 999.0 x10,000 times 999.0
F664 Specified trip 1 0 - 1 00 Times 0
F665 Specified trip2 0 - 1 00 Times 0
F666 Specified trip3 0 - 1 00 Times 0
0.0HzSTOP
14:06
F648 : Number of starting alarm
Min: 0.0 Max: 999.0
X1000 X100 X10 X1
0.0
