E6582062
7. Operating using external signals 7-6
4
4
4
7
9
■ List of the digital input terminal functions
Setting value
Input terminal function
Setting value
Input terminal function
Positive
logic
Negative
logic
(Inverse)
Positive
logic
Negative
logic
(Inverse)
0 1 No function 84 85 Terminal R2 output hold
23Fwd run 8889
Terminal Up frequency
*1
4 5 Rev run 90 91
Terminal Down frequency
*1
6 7 Standby 92 93 Terminal Up, Down frequency
clear
*1
8 9 Reset 1 94 95 Dancer correction OFF
10 11 Preset speed switching 1 96 97 Coast stop
12 13 Preset speed switching 2 98 99 Fwd/Rev
14 15 Preset speed switching 3 100 101 Run/Stop
16 17 Preset speed switching 4 102 103 Commercial power run switching
18 19 Jog run 104 105 FMOd/F207 priority switching
20 21 Emergency off 106 107 Terminal II priority
22 23 DC braking 108 109 Terminal operation priority
24 25 Acc/Dec switching 1 110 111 Parameter writing unlocked
26 27 Acc/Dec switching 2 112 113 Speed control/Torque control
switching
28 29 V/f switching 1 114 115 External equipment counter
30 31 V/f switching 2 116 117 PID 1, 2 switching
32 33 Stall prevention switching/Torque
limit switching 1
118 119 Preset speed switching 5
34 35 Torque limit switching 2 120 121 Quick deceleration 1
36 37 PID control OFF 122 123 Quick deceleration 2
38 39 Pattern operation 1 124 125 Preliminary excitation
40 41 Pattern operation 2 126 127 Brake
42 43 Pattern operation continuation 130 131 Brake answerback
44 45 Pattern operation start 134 135 Traverse operation
46 47 External thermal trip 136 137 Rescue operation
48 49 Communication priority cancel 138 139 Pump control switching
50 51 3-wire operation hold/stop 140 141 Fwd slowdown
52 53 PID differential/integral reset 142 143 Fwd stop
54 55 PID plus/minus switching 144 145 Rev slowdown
56 57 Forced run 146 147 Rev stop
