Toshiba TOSVERT VF-AS3 User Manual

E6582062
9. Measures to satisfy standards 9-2
9
(1) EMC Directive compliance of this inverter
The built-in EMC filter on the input side of this inverter (480 V class) reduces conducted noise
and radiated noise from input cables. The compliance with the EMC Directive is as shown in
the table below.
Category Subcategory
Product
standards
Test standard
Emission
Radiated noise
IEC61800-3
CISPR11 (EN55011)
Conducted noise CISPR11 (EN55011)
Immunity
Electrostatic discharge IEC61000-4-2
Radio-frequency electromagnetic field IEC61000-4-3
Electrical fast transient/burst IEC61000-4-4
Surge IEC61000-4-5
Conducted radio-frequency common
mode
IEC61000-4-6
Voltage dips, short interruptions and
voltage variations
IEC61000-4-11
Inverter type
Carrier
frequency
<F300>
Conducted noise
IEC61800-3 category C2
(EN55011 classB Group1)
Conducted noise
IEC61800-3 category C3
(EN55011 classB Group1)
Length of motor connecting cable Length of motor connecting cable
(kHz) (m) (m)
VFAS3-4004PC 4 50 150
VFAS3-4007PC 4 50 150
VFAS3-4015PC 4 50 150
VFAS3-4022PC 4 50 150
VFAS3-4037PC 4 50 150
VFAS3-4055PC 4 50 150
VFAS3-4075PC 4 50 150
VFAS3-4110PC 4 50 150
VFAS3-4150PC 4 50 150
VFAS3-4185PC 4 50 150
VFAS3-4220PC 4 50 150
VFAS3-4300PC 4 50 150
VFAS3-4370PC 4 50 150
VFAS3-4450PC 2.5 - 150
VFAS3-4550PC 2.5 - 150
VFAS3-4750PC 2.5 - 150
VFAS3-4900PC 2.5 - 150

Toshiba TOSVERT VF-AS3 Specifications

General

Model	TOSVERT VF-AS3
Category	Inverter
Overload Capacity	150% for 60 seconds
Cooling Method	Forced Air Cooling
Control Method	V/f control, Sensorless vector control
Braking Unit	Built-in
Communication Protocols	Modbus RTU, DeviceNet, Profibus DP
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault
Enclosure	IP20
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
